CNC Thread Grinding Stainless Steel from VT machining delivers precision Stainless Steel parts produced to your exact drawing. Thread grinding produces precise, high-finish threads on hardened parts and lead screws, and we tune every parameter to the behaviour of Stainless Steel, which is corrosion resistant, strong, hygienic (304/316 grades).
Process Data for CNC Thread Grinding Stainless Steel
| Wheel (supply condition) | Aluminium oxide (white/ceramic), soft grade |
|---|---|
| Depth per pass (rough / finish) | 0.01-0.03 / 0.002-0.005 mm |
| Achievable finish | Ra 0.2-0.4 µm |
| Typical size tolerance | Thread class 4h / lead ±0.003 mm per 25 mm |
Shown for 304 Stainless Steel, the most common Stainless Steel grade we see for CNC Thread Grinding. Typical values for 304 Stainless Steel, Annealed; confirmed on the first part.
CNC Thread Grinding Capability for Stainless Steel
- Pitch accuracy to grade 3
- Hardened-part threading
- Lead screws & gauges
- Fine surface finish
Stainless Steel material properties, finishing options and grade notes are on our CNC Surface Grinding Stainless Steel page.
How CNC Thread Grinding Stainless Steel Works
An abrasive wheel removes a fine, controlled layer from the Stainless Steel part. Wheel specification, dressing interval, infeed and coolant are matched to the alloy's hardness so the surface is not burned or left with residual stress.
Programming is driven directly by your 3D model or print. Work-holding, tool selection and the cutting strategy are planned around the critical features and the material before the first chip is cut. First-off inspection confirms the process is centred before production continues.
Achievable Tolerances for CNC Thread Grinding Stainless Steel
| Feature | Standard | Precision |
|---|---|---|
| Size (OD, ID, thickness) | ±0.005 mm | ±0.002 mm |
| Flatness over 100 mm | 0.010 mm | 0.003 mm |
| Parallelism | 0.010 mm | 0.003 mm |
| Roundness | 0.005 mm | 0.002 mm |
| Squareness | 0.010 mm | 0.005 mm |
| Surface finish | Ra 0.4 µm | Ra 0.1 µm |
| Workpiece hardness | up to 62 HRC | up to 65 HRC |
Standard is what a normal quotation assumes. Precision is available on nominated features and is priced separately, because it needs extra setups, in-process gauging and CMM verification. Call out only the features that need it — blanket-tightening a drawing is the single most common reason a quote comes back expensive.
Design Tips for CNC Thread Grinding Stainless Steel
We are happy to suggest design tweaks that improve manufacturability. Allowing adequate grind stock, specifying realistic flatness over the true datum, and relieving corners help us hit tight tolerances on Stainless Steel efficiently. If you send your model early, we will return practical DFM feedback before you commit to production.
CNC Thread Grinding Tolerances & Surface Finish
Ground Stainless Steel reaches single-micron tolerances on size, flatness and parallelism, with surface finishes down to Ra 0.1–0.4 µm — and a near-mirror finish on suitable alloys.
Exact achievable figures depend on the alloy, the feature size and the part geometry. Tell us which dimensions are critical and we will advise feasibility up front.
